HOPS12T : Point Source.

High Output 3-way Full Range Point Source for Mobile Applications

HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Size Comparison
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Photo
HOPS12T Size Comparison

Dual 12", 3-way high output system for mobile applications

  • Versatile 3-way high output, full range point source loudspeaker with a high power handling of 2000 W, interchangeable rotatable Instant Magnetic Waveguide, Quick Release Grill, integrated CMS system and flange adapter.


Main Features

  • 3-way high output point source optimised for mobile applications
  • Dynamic Airflow Cooling Technology
  • Superior sound with linear phase response
  • Full range audio with 44 Hz – 22 kHz (-6 dB)
  • High power with passive power handling of 2000 W (AES)
  • Crystal-clear sound from 1.4” mid/high coaxial ring-diaphragm neodymium driver
  • Ultra low distortion with dual 12” neodymium woofers
  • Instafit Magnetic Waveguide
  • More dispersion control with interchangeable, rotatable waveguides: 90° x 60° or 60° x 40°
  • Quick Release Grille
  • Extreme durability from the multiplex enlosure with polyurea coating
  • Simple mounting with a range of accessories
  • System integration with LINUS Loudspeaker Management Amplifiers

This post is also available in: Deutsch (German)

Overview

The HOPS12T is a 3-way high output point source system, perfect for mobile use. Its characteristics mean the speaker stuns and impresses with superior sound reinforcement at short and medium distances for corporate, sport and political events, small festivals, bands, mobile DJs, side fill in large systems and many more.

The full-range system is equipped with two 12″ neodymium cone speakers and a dual annular ring diaphragm driver coaxial system, with 3.5″/1.75“ voice coils. This meticulously designed technology covers the whole frequency range, from 44 Hz to 22 kHz (-6dB), with perfect clarity . The unique shape and technical characteristics of CODA Audio’s revolutionary ring-diaphragm drivers clearly distinguish them from conventional high-frequency compression drivers. They produce a consistent and phase-coherent wavefront and have audible and measurable advantages in terms of efficiency, dynamic range and distortion-free fidelity.

The power handling and sound pressure level have been smartly optimised by using CODA Audio’s patented Dynamic Airflow Cooling Technology to reduce power compression in the loudspeaker. In this way, power handling, sound pressure level and dynamics are significantly increased and permanently maintained.

The HOPS12T features a 90° x 60° or 60° x 40° rotatable Instafit Magnetic Waveguide that can be easily adapted without tools.

The cabinet features the Quick Release Grille and CODA Audio CMS (CODA mobile suspension) quick-connect system with a convenient workflow. On the bottom of the HOPS12T there is a flange, for a 36mm distance tube. A wide range of accessories give simple integration across a variety of applications. Accessories include fast mounting horizontal and vertical U-brackets, stand fitting adapter, quick lock flying frame and more.

You can enhance the bass levels even further, for a spectacular low-end. With complementary subwoofers U4-Sub or SCP, the system’s bandwidth can be expanded down to 25 Hz. Thanks to the System Optimiser 3D direct sound simulation software, even complex setups can be simulated quickly and meaningfully.

Like all CODA Audio systems, the HOPS12T is designed to work with LINUS system amplifiers and racks, so the user can enjoy the highest performance and maximum operational reliability.

Durable and robust, the enclosure of the HOPS12T is a hybrid of birch plywood and aluminium with a moisture and UV-resistant black polyurea finish in RAL9005. The system can be supplied in other RAL colours on request. The front is protected by a stable honeycomb grille with waterproof foam behind it, that is still acoustically transparent.

With IP54 protection against dust and light or splashing water, it is ideally suited for temporary outdoor use. For permanent outdoor use, the HOPS12 is also available in IP55 with full jet water protection.

All CODA Audio products feature quality craftsmanship, are made in Europe, and come with a 5-year manufacturer’s warranty.

The perfect mobile loudspeaker, the HOPS12T, is also available as HOPS12i installation version.

System Solutions

NO. 1: Full Range 4-8x HOPS12

FULL RANGE

SYSTEM COMPONENTS:

4-8x HOPS12
1x LINUS14D

NO. 2: Sub / Top 2x HOPS12 + 2x U4

SUB / TOP

SYSTEM COMPONENTS:

2x HOPS12
2x U4
1x LINUS14D

NO. 3: 4-POINT CLUB 4x HOPS12 + 2x U4

4-POINT CLUB

SYSTEM COMPONENTS:

4x HOPS12
2x U4
1x LINUS14D

Specification



Type: High Output 3-way Full Range Point Source for Mobile Applications
Application: 3-way high output, full range point source for mobile applications
Frequency response: 44 Hz – 22 kHz (-6 dB)
Power handling Low AES / peak: 2000 W / 8000 W
Max. peak SPL (with LINUS14):* HOPS12T-64: 144 dB (A)
HOPS12T-96: 142 dB (A)
Amplification, cabinets per amplifier
LINUS12C Optimum / Maximum: 8/12
LINUS14 Optimum / Maximum: 8/12
Dispersion horizontal: HOPS12T-64: 60° (rotatable)
HOPS12T-96: 90° (rotatable)
Dispersion vertical: HOPS12T-64: 40° (rotatable)
HOPS12T-96: 60° (rotatable)
Components Low frequency: 2x 12″ neodymium, water resistant cones,
4″ (101 mm) VC, 1000 W (AES) each
Components Mid/High frequency: 1.4″ neodymium coaxial driver,
MF: 3.5″ (90 mm) VC, 150 W (AES)
HF: 1.75″ (44.4 mm) VC, 80 W (AES)
Crossover point: 3-way passive 440 Hz / 6300 Hz
Input connectors: 2x Neutrik™ NL4MP
Nominal impedance LF / MF+HF: 8 Ω (1+/1-)
Enclosure material: Hybrid birch plywood and aluminium
Finish: Polyurea black coating
Suspension: CMS + flange adapter, M8 threaded points for additional U-bracket
IP rating (IEC 60529): IP54
Weather protection options: Standard IP55: IP55 (direct cable)
MG1 (Marine Grade 1): IP55
Dimensions (WxHxD): 368 x 790 x 420 mm / 14.49 x 31.1 x 16.54″
Net weight: 36.2 kg / 79.81 lbs

* Measured with pink noise 12 dB crest factor (A-weighted).
** In low SPL applications up to 4x HOPS12T per channel can be connected.

Accessories

  • H12TH

    This post is also available in: Deutsch (German)

    Fast mounting horizontal U-bracket

  • H12TV

    This post is also available in: Deutsch (German)

    Fast mounting vertical U-bracket

  • H12TSF

    This post is also available in: Deutsch (German)

    Stand fitting adapter

  • FRH-APS

    This post is also available in: Deutsch (German)

    Quick lock flying frame for horizontally arrayed APS or HOPS12T

  • WAVEGUIDE HOPS12T 64

    This post is also available in: Deutsch (German)

    Waveguide for HOPS12T 60°x40°

  • FC-HOPS12

    This post is also available in: Deutsch (German)

    Flight case for 2x HOPS12

Downloads

FileAction
HOPS12T Data Sheet (English)Download
HOPS12T Datenblatt (Deutsch)Download
HOPS12T CAD Drawing 2DDownload
HOPS12T CAD Drawing 3DDownload
HOPS12T Accessories - DrawingsDownload
CODA Audio Weather Protection Download
