LINUS12C :

4 Channel DSP Amplifier with Loudspeaker Management

LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo
LINUS12C Photo

Integrated DSP, network and amplifier solution, 4x 3000 W @ 4 Ω

  • 19“/ 2U Four channel DSP amplifier for fixed installations, touring and portable applications, delivers 4x 3000 W / 4 Ω


Main Features

  • Integrated DSP, network and amplifier solution
  • 4x 3000 W @ 4 Ω
  • Class D-IC amplifiers for superior sound performance
  • SMPS with automatic selection for 115 V or 230 V
  • SHARC floating point DSP @ 96 kHz
  • 4 balanced analogue inputs
  • LiNET – 8x freely configurable digital audio signals over CAT5e
  • Advanced IIR and linear phase FIR filters
  • LINUS Control – network control and monitoring of amplifiers over Ethernet
  • Factory presets for CODA Audio loudspeaker systems
  • 5 year warranty

This post is also available in: Deutsch (German)

OVERVIEW

The LINUS12C is a four channel DSP networkable amplifier delivering 4x 3000 W of virtually distortion-free power in a light weight 19”/2U package. The 4 audio inputs are selectable from analog, AES3 or LiNET digital audio and are routable to any of the 4 outputs.

LINUS12C ENGINE – the class D-IC output stage topology delivers audiophile sonic accuracy with enormous headroom providing significant improvement of the system performance in dynamics and transparency.

LINUS CORE – the SHARC floating point DSP processor ensures tremendous processing power enabling the integration of sophisticated audio algorithms. The advanced signal processing includes IIR and phase linear DS-FIR filters for perfect linearity and superior sound performance as well as advanced look-ahead and frequency dependent limiters for increased system headroom and sonic fidelity under heavy use conditions.

LiNET – a robust, redundant audio transport solution that transmits digital audio over a shielded CAT5e cable. Up to 8 digital audio signals can be sent to each amplifier via LiNET, buffered and sent to the next unit via the LiNET link out for daisy chaining. The signal routing inside the LINUS12C can be done remotely or using the pushbuttons on the front panel.

LINUS Control – CODA’s intuitive  system management software provides the user a fast and flexible graphical interface for everything from system configuration and tuning,  to control and system monitoring. It is optimised for both Mac OS and Windows, including tablet and native interfaces.

APPLICATIONS

Containing factory presets for CODA Audio loudspeaker systems LINUS12C offers a flexible solution for touring, permanent installation, corporate AV and portable applications.

Factory presets LINUS12C:
ViRAY, N-RAY, TiRAY, CoRAY, APS Series, N-APS Series, HOPS Series, CUE Series, G-Series, D-Series, U-Subs.

Specification

GENERAL
Number of output channels 4
Output stage Class D-IC
Internal samplerate / bit-depth 96 kHz / 24 bit
Signal-to-noise ratio
(22 Hz – 20 kHz, 4 Ω – analogue input)
>108 dB (unweighted)
>111 dB (A-weighted)
Signal-to-noice ratio
(22 Hz – 20 kHz, 4 Ω – digital input)
>116 dB (unweighted)
>119 dB (A-weighted)
Frequency response
(8 Ω load with CLEAR preset)
20 Hz – 20 kHz = (+0.0 dB /-1.0 dB)
THD+N & IMD
(4 Ω load @ 1/2 output power)
20 Hz – 20 kHz = < 0.005%
Latency
(input to loudspeaker output)
Minimum 2.70 ms AES/EBU input
Minimum 2.00 ms analog input
Protection circuits Inrush current limiter
Thermal limiter
Output DC
SMPS over-current
Output overload
LED indicators Mute status
Limit
Signal
Protection
Ethernet control active
Digital signal locked
Power on
Ethernet connection 2 x 100 Mbps RJ45 Control
AC Mains
AC mains input connector Neutrik 32A powerCON®
AC mains voltage (high range)**
(dual voltage SMPS with automatic voltage range selection)
180 V = Minimum
230 V = Nominal
265 V = Maximum
AC mains voltage (low range)**
(dual voltage SMPS with automatic voltage range selection)
90 V = Minimum
115 V = Nominal
132 V = Maximum
AC mains frequency 47 – 63 Hz
Power consumption*
(1/4 power = 500 W @ 4 Ω to represent typical music signal)
Amplifier in standby = 17.6 W
Amplifier idle = 191 W
Amplifier ¼ power = 2800 W
Input
Input sources Analog & AES/EBU
Analogue input impedance
(balanced)
12 kΩ
Maximum input level (analogue differential) +18 dBu / 6.15 Vrms
Input connections 4x XLR3 Analog IN
1X RJ45 LINET IN (8x CH)
1x RJ45 LINET LINK (8x CH)
1x RJ45 AUX
Supported digital input formats
(internal SRC)
32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz / 176.4 kHz / 192 kHz
Output
RMS output power*
(20 Hz – 20 kHz, THD <0.01%)
(all channels driven)
1600 W @ 8 Ω
3000 W @ 4 Ω
4000 W @ 2.7 Ω
4100 W @ 2 Ω
Peak output power*
(20 Hz – 20 kHz, 6 dB Crest Factor)
(all channels driven)
3200 W pk @ 8 Ω
6000 W pk @ 4 Ω
5500 W pk @ 2.7 Ω
4800 W pk @ 2 Ω
Maximum output voltage* +/- 155 V pk
Maximum output current* +/- 52 A pk
Damping Factor
(8 Ω load, 1 kHz & below)
2500
Minimum output load 2 Ω nom
Power output connections 2x Neutrik NL4 speakON®
1x Neutrik NL8 speakON®
Thermal
Operating temperature +5°C to +55°C
41°F to 131°F
Thermal output
(BTU/h)
679.02 = Idle
2124 = 20 %
4437 = 50 %
8287 = 100 %
Thermal output
(kWh)
0.199 = Idle
0.623 = 20 %
1.300 = 50 %
2.429 = 100 %
Cooling 2x thermally controlled fans
Hot air expelled at rear
Physical
Dimensions (WxHxD) 483.5 x 88 x 454.18 mm / 19.04” x 3.46” x 17.88” (2U)
Shipping Dim. (WxHxD) 675 x 130 x 560 mm (0.049 m³) / 26.57” x 5.12” x 22.05”
Net Weight 14.70 kg / 32.4 lbs.
Shipping weight 17.5 kg / 38.6 lbs.
Volume = 0.049 m3 / 1.73 ft3

* Typical values – some variation may exist due to component tolerances.
**Voltage range should not be exceeded. Amplifier output power performance will degrade below nominal voltage & increase above nominal voltage.
