SCV-F : Sensor Controlled Subwoofer.

Compact 18" Sensor Controlled Subwoofer

SCV-F Photo
SCV-F Photo
SCV-F Photo
SCV-F Photo
SCV-F Photo
SCV-F Size Comparison
SCV-F Photo
SCV-F Photo
SCV-F Photo
SCV-F Photo
SCV-F Photo
SCV-F Size Comparison

Compact 18” sensor controlled subwoofer, Extended frequency range down to 25 Hz (-6 dB)

  • The CODA Audio award winning sensor controlled technology is extended with the compact SCV-F subwoofer. Combining a closed feedback-loop control with large, low noise laminar flow ports the SCV-F subwoofer offers increased output and well controlled response.


Main Features

  • Compact 18” sensor controlled subwoofer
  • Extended frequency range: 25 Hz – 150 Hz (-6 dB)
  • Power handling: 1500 W (AES)
  • Sensor Control Technology
  • The feedback loop control ensures extreme fast transient response and ultra low distortion
  • Rigging is compatible to AiRAY and VIRAY
  • Subwoofer arrays can be curved for perfect time alignment with AiRAY and ViRAY
  • Flyable or ground stackable in cardio or omni configurations
  • System integration with LINUS Loudspeaker Management Amplifiers




This post is also available in: Deutsch (German)

Overview

When it comes to subwoofers, CODA Audio has a sizeable offering of extremely smart boxes for a wide range of applications. What’s particularly smart about these subs is the fact they are sensor controlled, which means they’re way ahead of the field from the offset: these speakers are capable of delivering measurable and very audible advantages in impulse response, group delay, waterfall, and the distortion domain.

In short, between 35 and 100 Hz, the audio is time aligned; and the group delay increases slightly in the 25-35 Hz range. As a result, you get an extremely precise and musical low end, with sonic qualities that go way beyond any conventional port loaded system.

At the core of SCV-F (which works in Cardio or omnidirectional mode) is its very efficient, high output 18″ long neodymium excursion woofer, which provides a completely flat response down to 25 Hz (-6 dB), and hardly any distortion at all.

Then, as with all CODA products, comes the unique driver capabilities: SCV-F has a built in ‘velocity sensor’ within its 18″ driver, which measures the exact movement of the voice coil by sending information over XLR cable to the Comparator about velocity, excursion, and speed of the voice coil itself.  In turn, the Comparator then compares the original input signal to the movement measurement from the ‘velocity sensor’, and adjusts the amplifier driving voltage and/or current, so the diaphragm can move the way it should move. The Comparator brings Total Harmonic Distortion (THD) down by a massive 80-90%.

SCV-F was primarily designed to be the perfect LF extension to CODA’s ViRAY line arrays, though it is also suited for a variety of applications in touring and installations, particularly where small footprint, pristine sonic coverage, and controllable bass are paramount.

SCV-F has been designed to work exclusively with CODA Audio LINUS Loudspeaker Management Amplifiers as an integrated solution for DSP, amplification, network remote control, optimal performance, protection, as well as extensive possibilities for system tuning and monitoring.



System Solutions

VIRAY 1.5 BI-AMP MONO COMBI

SYSTEM COMPONENTS:

4x ViRAY (Bi-Amp)

3x SCV-F

1x LINUS RACK20
1x FRT-VR

CABLES:

1x CAL4SP-20

1x CAHSCP-20

1x CAL4SP-1.5

OPTIONAL:

1x FC-VR

1x DOT-SCV-F

1x CO-SCV-F-3

1x DOT RC Dolly

1x FR-VR

Mono System

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACK20:    Optimum         Maximum

ViRAY                                          4                     6

SCV-F Cardio                               3                     6

SCV-F Omni                               2+2                 4+4

VIRAY 1.6 BI-AMP MONO COMBI

SYSTEM COMPONENTS:

4x ViRAY (Bi-Amp)

3x SCV-F

1x LINUS RACK20
2x FR-VR

CABLES:

1x CAL4SP-20

1x CAHSCP-20

1x CAL4SP-1.5

OPTIONAL:

1x FC-VR

1x DOT-SCV-F

1x CO-SCV-F-3

1x DOT RC Dolly

Mono System

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACK20:    Optimum         Maximum

ViRAY                                               4                     6

SCV-F Cardio                                    3                     6

SCV-F Omni                                    2+2                 4+4

VIRAY 1.7 BI-AMP MONO GROUNDSTACK

SYSTEM COMPONENTS:

3x ViRAY (Bi-Amp)

3x SCV-F

1x LINUS RACK20
1x VGA

CABLES:

1x CAL4SP-20

1x CAHSCP-20

1x CAL4SP-1.5

OPTIONAL:

1x FC-VR

1x DOT-SCV-F

1x CO-SCV-F-3

1x DOT RC Dolly

Mono Groundstack System

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACK20:    Optimum         Maximum

ViRAY                                            3                     6

SCV-F Cardio                                 3                     6

SCV-F Omni                                 2+2                 4+4

VIRAY 1.8 SCV-F CARDIO MODE

SYSTEM COMPONENTS:

12x SCV-F

1x LINUS RACK20

CABLES:

2x CAHSCP-20

4x CAL4SP-1.5

OPTIONAL:

2x DOT-SCV-F

2x CO-SCV-F-3

1x DOT RC Dolly

SCV-F Sub extension

Cabinets per RC20:    Optimum         Maximum

SCV-F Cardio                      6                     12

SCV-F Omni                  2+2+2+2         4+4+4+4

VIRAY 2.3 PASSIVE STEREO GROUNDSTACK

SYSTEM COMPONENTS:

6x ViRAY

6x SCV-F

1x LINUS RACK20

2x VGA

CABLES:

2x CAHSC-20

2x CAL4SP-1.5

2x CAY-3

OPTIONAL:

2x FC-VR

2x DOT-SCV-F

2x CO-SCV-3

1x DOT RC Dolly

Passive ViRAY + SCV-FR – 120 Hz optimized for small flown or ground stacked arrays

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACK20:    Optimum         Maximum

ViRAY                                            2×3                  2×6

SCV-F Omni                                   2×2                  2×4

Presets:

Combi system preset for ViRAY + SCV-F / SCP SUB combinations:

ViRAY-P+SCVOm100

ViRAY in passive mode + SCV or SCP in omni mode

VIRAY 2.4 PASSIVE COMBI STEREO

SYSTEM COMPONENTS:

8x ViRAY
6x SCV-F

1x LINUS RACK20
2x FRT-VR Frame

CABLES:

2x CAHSC-10

2x CAY-3

2x CAL4SP-10

4x CAL4SP-1.5

OPTIONAL:

2x FC-VR

2x DOT-SCV-F

1x DOT-RC Dolly

1x CO-SCV-3 Cover

1x DOL-SCV

1x CO-SCV

2x FR-VR

Passive ViRAY + Ground stacked SCV-F stereo

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACL20:    Optimum         Maximum

ViRAY                                           2×4                  2×6

SCV-F Omni                                 2×2                  2×4

Presets:

Combi system prest for ViRAY + SCV-F / SCP SUB combinations:

ViRAY-P+SCVOm100

ViRAY in passive mode + SCV or SCP in omnio mode

VIRAY 2.5 PASSIVE COMBI MONO

SYSTEM COMPONENTS:

8x ViRAY
3x SCV-F

1x LINUS RACK20
1x FRT-VR Frame

CABLES:

1x CAL4SP-20

1x CAY-2

1x CAHSCP-20

1x CAL4SP-1.5

OPTIONAL:

2x FC-VR

1x DOT-SCV-F

1x DOT-RC Dolly

1x CO-SCV-3 Cover

1x FR-VR

Passive ViRAY + Ground stacked SCV-F mono

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACK20:    Optimum         Maximum

ViRAY                                            2×4                  2×6

SCV-F Cardio                                  3                      6

SCV-F Omni                                  2+2                  4+4

VIRAY 2.6 PASSIVE COMBI MONO

SYSTEM COMPONENTS:

8x ViRAY
6x SCV-F

1x LINUS RACK20
1x FR-VR Frame
1x FRT-VR Frame

CABLES:

1x CAL4SP-20

1x CAY-2

1x CAHSCP-20

2x CAL4SP-1.5

OPTIONAL:

2x FC-VR

1x DOT-SCV-F

1x DOT-RC Dolly

1x CO-SCV-3 Cover

1x DOT-SCV Dolly

1xCO-SCV-F

Passive ViRAY + Ground stacked SCV-F mono

Frequency range (-6 dB): 25 Hz – 22 kHz

Cabinets per LINUS RACK20:    Optimum         Maximum

ViRAY                                         2×4                  2×6

SCV-F Cardio                                3                      6

SCV-F Omni                                2+2                  4+4

Specification



Type: Compact 18″ Sensor Controlled Subwoofer
Application: Compact subwoofer
Frequency response: 25 Hz – 150 Hz (-6 dB)
Power handling (AES / peak): 1500 W / 6000 W
Sensitivity 1 W / 1 m:* 100 dB
Maximum output peak:** 138 dB
Amplification, Cabinets per Amplifier:
LINUS14 Optimum / Maximum: 8/12
Components: 18″ neodymium ultra low distortion woofer, 4″ (101.6 mm) VC, 1500 W (AES) each
Nominal impedance: 8Ω (1+/1-)
Input connectors: 2x Neutrik™ NL4MP (rear) + 1x Neutrik™ NL4MP (front)
Velocity sensors output: Neutrik™ NC3MAV (rear) + Neutrik™ NC3MAV (front)
Suspension: Flying hardware integrated, allows curving (0°, 2.5°, 5°)
Enclosure material: Birch plywood
Finish: Polyurea black coating
IP rating (IEC 60529): IP54
Weather protection options: Standard IP55: IP55 (Amphenol connectors)
MG1 (Marine Grade 1): IP55
Dimensions (WxHxD): 675 x 490 x 790 mm / 26.57 x 19.29 x 31.1″ (incl. hardware)
Net weight: 57 kg / 125.66 lbs

* Measured with pink noise 6 dB crest factor. Half space loading.

Accessories

  • FR-VR

    This post is also available in: Deutsch (German)

    Heavy duty frame for flying or ground stacking ViRAY and/or SCV-F and/or SC2-F

  • EXBAR-VR

    This post is also available in: Deutsch (German)

    Extension bar for FR-VR frame / SCV-F

  • SH-VR

    This post is also available in: Deutsch (German)

    Shackle for FR-AR and FR-VR

  • TILT-VR

    This post is also available in: Deutsch (German)

    Tilting leg Set for ground stacking ViRAY / SCV-F on FR-VR

  • DOL-SCV

    This post is also available in: Deutsch (German)

    Front dolly for single SCV-F/SC2-F

  • DOT-SCV

    This post is also available in: Deutsch (German)

    Transport dolly for up to 4x SCV-F/SC2-F

  • CO-SCV-1

    This post is also available in: Deutsch (German)

    Protection cover for single SCV-F/SC2-F

  • CO-SCV-2

    This post is also available in: Deutsch (German)

    Protection cover for 2x SCV-F/SC2-F

  • CO-SCV-3

    This post is also available in: Deutsch (German)

    Protection cover for 3x SCV-F/SC2-F

  • CAH-SCP-10

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor system cable, 10 m
    1xNL4 speakon® +1x 5-POLXLR-M
    2xNL4 speakon® +2x 3-POLXLR-F

  • CAH-SCP-20

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor system cable, 20 m
    1xnl4 speakon® +1x 5-polxlr-m
    2xnl4 speakon® +2x 3-polxlr-f

  • CAH-SCP-Y

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor cable splitter

  • CAH-SCP-EX-10

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor cable extension 10 m

  • CAL4SP-1.5

    This post is also available in: Deutsch (German)

    4-pole loudspeaker cable, 4×4 mm, 1.5 m
    1x nla4 speakon®

Downloads

FileAction
SCV-F Data Sheet (English)Download
SCV-F Datenblatt (Deutsch)Download
GLL-file for EASE and EASE Focus (ViRAY, SCV-F)Download
Loading Capacity Calculation (ViRAY_SCV-F_SC2-F)Download
SCV-F CAD Drawing 2DDownload
SCV-F CAD Drawing 3DDownload
SCV-F Accessories - DrawingsDownload
CODA Audio Rigging Systems maintenance AiRAY+SC2-SCV-FDownload
CODA Audio Rigging Systems maintenance ViRAY and SCV-FDownload
CODA Audio Cardioid DeploymentsDownload
CODA Audio Weather Protection Download
