D20 : Point Source.

True Full Range 3-way Installation System

D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo
D20 Photo

3-way coherent point source technology, true full range performance (35 Hz – 20 kHz), 8”/1.75” coaxial driver and 12” extremely high excursion cone driver

  • The D20 is a passive 3-way compact system, designed for small to medium installation applications where extended low frequencies, superior dispersion control and high fidelity sound are required.


Main Features

  • 3-way coherent point source technology
  • True full range performance (35 Hz – 20 kHz)
  • 8”/1.75” coaxial driver and 12” extremely high excursion cone driver
  • High power handling of 1000 W (AES)
  • Symmetrical coverage of 90°
  • Superior sound quality
  • Optimised for near-field applications
  • High output before feedback
  • System integration with CODA DSP amplifier
  • Integrated M6 flying points

This post is also available in: Deutsch (German)

Overview

History

Large studio monitors are engineered to produce extended low frequencies at low levels. In opposite full range PA loudspeakers are not really full range; they are optimised for high efficiency above 60 Hz so require additional subwoofers to extend the lower frequency range.

There are few if any professional solutions for a compact cabinet providing extended low frequency at high SPL. D20 is such a solution – a compact 3-way point source designed without compromise to provide extended low frequency at high level.

Description

The D20 is a passive 3-way compact system, designed for small to medium installation applications where extended low frequencies, superior dispersion control and high fidelity sound are required.
The cabinet contains an extremely long excursion 12” woofer and an 8”/1.75” coaxial driver.
The advanced design aligns the acoustical centers of the transducers to produce a single point source. This unique loudspeaker technology provides a coherent wave front without hot spots. Precise directivity ensures uniform coverage with perfect time alignment between the components.

True Full Range

The cabinet contains an extremely long excursion 12” ultra low distortion cone driver covering the range 35 Hz – 400 Hz. The 3” voice coil is 32 mm high, ensuring linear excursion of 22 mm / pp at consistent magnetic force. Three aluminum shorting rings reduce inter-modulation distortion; minimise induction variation while reducing thermal compression. This design reduces dramatically the distortion of a typical subwoofer at longer excursion levels, and improves the overall sound quality providing deep and punchy bass.

True Coherent

At the heart of the D20 is the new developed 8”/1.75” coaxial driver. The 8” cone midrange covers the 200 – 1800 Hz range with high efficiency and smooth, linear response. The high frequency driver contains an ultra light 1.75” annular diaphragm providing exceptional transient response with very high efficiency from 1kHz to 20 kHz. This new transducer was engineered to radiate a single source, coherent 90° wave front for superior dispersion control and high fidelity sound.

Controlled Dispersion at High SPL

The low and mid range are overlapped in the range 200 – 400 Hz while mid and high range are overlapped in the 1 – 1.8 kHz range. This increases the maximal SPL of the system providing improved directivity control.

System Solution

The D20 is designed to work exclusively with dedicated CODA Audio DSP amplifiers as an integrated solution for DSP control, amplification, network remote control and diagnostic. The integrated solution ensures optimal performance and protection.

Options

Additional colours and weather protection options are available on request.

Applications

Designed for small to medium installation applications where extended low frequency range at high level is required but no subwoofers can be used. In fact two D20 systems will deliver same level of low frequency range and output as a single 18” subwoofer.

System Solutions

NO. 1: 8x D20

SYSTEM COMPONENTS:

8x D20
1x LINUS5-C / LINUS10-C

NO. 2: 4x D20 + 2x G18-SUB

SYSTEM COMPONENTS:

4x D20
2x G18-Sub
1x LINUS10-C

Specification

Type: Full Range Passive 3-way Installation System
Application: Superior quality near-field applications with extended low range
Frequency response: 35 Hz – 21 kHz (-6 dB)
Power handling AES: 1000 W
Peak power: 4000 W
Sensitivity: 97 dB*
Max. SPL peak: 133 dB**
Dispersion: 90° conical
Components:
Low frequency: 12″ woofer, 1000 W (AES)
Mid/High frequency: 8″/1.75″ coaxial driver, Mid: 2″ (51 mm), High: 1.75″ (44.4 mm) voice coil, 180 W + 80 W (AES)
Crossover: 300 Hz, 1.3 kHz passive
Nominal impedance: 4 Ω
Cabinets per amp channel: 1***
Input connectors: 2x Neutrik™ NL4MP
Suspension: 10x M6 threaded points
Enclosure material: Birch plywood
Finish: Polyurea black coating (water resistant)
Dimensions (WxHxD): 342 x 700 x 425 mm / 13.46 x 27.56 x 16.73″
Net weight: 26 kg / 57.32 lbs
Weatherproof version: Optional

* Measured with pink noise 6 dB crest factor.

**Half-space loading.
*** In low SPL applications up to 2x D20 per channel can be connected.

Accessories

  • CUD20V

    This post is also available in: Deutsch (German)

    Vertical u-bracket for D20

  • CUD20H

    This post is also available in: Deutsch (German)

    Horizontal u-bracket D20

  • AK2D

    This post is also available in: Deutsch (German)

    Array kit for 2 x D12 / D20

  • 24481

    This post is also available in: Deutsch (German)

    Wall Mount for CoRAY / CoRAY4L Twin, fixed on CA4 / 1x CoRAY4i or CoRAY4i twin, fixed on CA4i / G515-Pro / G512-Pro / G715-Pro / G712-Pro / D12 / D20

  • M6 RING

    This post is also available in: Deutsch (German)

    For rigging G308 / G308-Pro / G515-Pro / G512-Pro / G715-Pro / D8 / D12 / D20
