APS-SUB : Arrayable Point Source. Multipurpose Subwoofer.

Flyable 18" Subwoofer for APS

APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Size Comparison
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Photo
APS-SUB Size Comparison

Compact 18" subwoofer, Extended frequency range down to 28 Hz (-6 dB)

  • A 18" high output subwoofer that provides powerful and extended low frequency response with immense headroom. Low port compression and optimised enclosure design give a tight, accurate bass response that is ideally suited for dance clubs, mobile and installation applications.


Main Features

  • 18″ ultra low distortion woofer
  • Extended frequency range: 28 Hz – 150 Hz (-6 dB)
  • High power handling: 1,250 W (AES)
  • Maximum SPL 138 dB (peak)
  • Rigging compatible with APS
  • Flyable or ground stackable
    in cardio or omni configurations
  • System integration with LINUS DSP amplifiers

This post is also available in: Deutsch (German)

Overview

The APS-SUB is an 18″ high output subwoofer that provides powerful and extended low frequency response with immense headroom. Low port compression and optimised enclosure design give a tight, accurate bass response that is ideally suited for dance clubs, mobile or installation applications. The integrated rigging system allows quick and easy flying or ground stacking.

The APS-SUB is equipped with an extremely long excursion 18″ ultra low distortion driver. The strong motor delivers extreme high magnetic flux for increased efficiency. The 4″ voice coil ensures ultra linear excursion of 20 mm / pp at consistent magnetic force.
The state-of-the-art carbon-fiber cone ensures maximum stiffness and low moving mass. Three aluminum shorting rings reduce intermodulation distortion, minimising induction variation whilst reducing thermal compression. This design dramatically reduces the distortion of a typical subwoofer at longer excursion levels, and improves the overall sound quality and performance characteristics of the cabinet.
The APS-SUB is designed to work exclusively with CODA Audio LINUS amplifiers as an integrated solution for DSP control, amplification, network remote control and diagnostics.
The integrated solution ensures optimal performance and protection.

Primarily designed as a subwoofer extension for APS, the APS-SUB is also suited for a variety of applications in touring and installations where compact size, high precision, deep bass with directivity control is needed.
Typical applications are dance clubs, theaters, houses of worship and live sound venues.

System Solutions

NO. 2: 6x APS + 6x APS-SUB

SYSTEM COMPONENTS:

6x APS
6x APS-SUB
1x LINUS14
2x LID-APS-SUB
2x GAH-APS
2x CAL4SP-10
6x CAL4SP-1,5
4x CAB4
2x FC-APS
2x DOT-APS-SUB
2x CO-APS-SUB-3

NO. 3: 8x APS-SUB

SYSTEM COMPONENTS:

8x APS-SUB
1x LINUS14
2x CAL-Comb1
4x DOT-APS-SUB

NO. 4: 8x APS-SUB

SYSTEM COMPONENTS:

8x APS-SUB
1x LINUS14
2x CAL-Comb1
4x DOT-APS-SUB

2x APS + 2x APS-SUB

SYSTEM COMPONENTS:

2x APS
2x APS-SUB
1x LINUS12C (LINUS14)
2x CU-APS
1x DOT-APS-SUB
4x CAL4SP-10

Specification



Type: Flyable 18″ Subwoofer for APS
Application: Small / Medium venues
Frequency response (-6 dB): 28 Hz – 150 Hz
Power handling AES / peak (passive): 1250 W / 5000 W
Sensitivity 1W / 1m:* 98 dB
Maximum output peak:** 138 dB
Amplification, cabinets per amplifier:
LINUS10-C Optimum / Maximum: 8/12
LINUS12C Optimum / Maximum: 8/12
LINUS14 Optimum / Maximum: 8/12
Components: 18″ ultra low distortion woofer, 4″ (101.6 mm) VC, 1300 W (AES)
Nominal impendance: Ω (1+/1-)
Input connectors: 2x Neutrik™ NL4MP
Suspension: Integrated
Enclosure material: Baltic birch
Finish: Polyurea coating
IP rating (IEC 60529) IP54
Weather protection options: Standard IP55: IP55 (Amphenol connectors)
MG1 (Marine Grade 1): IP55
Dimensions (WxHxD): 674 x 570 x 596 mm / 26.54 x 22.44 x 23.46″
Net weight: 45 kg / 99.21 lbs

* Pink noise 6 dB crest factor. Half-space loading.

Accessories

  • FRV-APS

    This post is also available in: Deutsch (German)

    Frame for vertically arrayed APS or APS-SUB

  • FRV-DA-APS

    This post is also available in: Deutsch (German)

    Pullback adapter plates for vertical arrayed APS or APS-SUB

  • DOT-APS-SUB

    This post is also available in: Deutsch (German)

    Transport dolly for 3x APS-SUB

  • LID-APS-SUB

    This post is also available in: Deutsch (German)

    Groundstack adapter plate for horizontally arrayed APS on APS-SUB

  • GAH-APS

    This post is also available in: Deutsch (German)

    Groundstack adapter for horizontally stacked APS

  • CAL-COMB1

    This post is also available in: Deutsch (German)

    Loudspeaker Cable (2CH), NL4 to 2x NL4 (1+/1-) – 10m

Downloads

FileAction
APS-SUB Data Sheet (English)Download
APS SUB Datenblatt (Deutsch)Download
APS-V1-1 GLL-FileDownload
APS Loading CapacityDownload
APS-SUB CAD Drawing 2DDownload
APS-SUB CAD Drawing 3DDownload
APS-SUB Accessories - DrawingsDownload
CODA Audio Weather Protection Download
