G715-Pro : Point Source.

High Output 3-way Multidesign System

G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Size Comparison
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Photo
G715-Pro Size Comparison

3-way high output versatile full range system, Unique 1.4" mid/high coaxial neodymium driver

  • A versatile full range three-way loudspeaker system that features a high power 15" neodymium woofer and a 1.4" mid/high coaxial neodymium driver coupled to a 90° x 60° rotatable elliptical waveguide.


Main Features

  • 3-way compact versatile full range system
  • Frequency range: 50 Hz – 23 kHz (-6 dB)
  • Unique 1.4″ mid/high coaxial neodymium driver
  • 90°x60° rotatable elliptical waveguide
  • 15″ neodymium ultra low distortion woofer
  • Passive or bi-amplified operation
  • Multidesign enlosure with monitor function
  • Designed for fixed installation, touring and stage monitoring
  • Available as left and right version
  • Ball impact resistant (DIN 18032-3)
  • System integration with LINUS Loudspeaker Management Amplifiers

This post is also available in: Deutsch (German)

Overview

The G715-Pro is a compact, high-performance 3-way multifunctional loudspeaker, designed to meet the highest standards. It delivers an output which far exceeds expectations for such a compact system.

Thanks to the unique coaxial 1.4″ neodymium ring diaphragm driver, the G715-Pro boasts impressive directivity, exceptional speech intelligibility and transparent audio. The high-excursion 15″ neodymium cone driver offers reduced power compression and provides controlled low frequency response down to 50 Hz.

The rotatable 90°x60° elliptical waveguide, stage monitor usability, integrated flange adapter, and numerous M6 and M8 mounting points, guarantee maximum flexibility. The G715-Pro is suitable for a wide range of applications, including main system, stage monitor, front fill or delay line.

The G715-Pro can be operated either in 1-way passive or 2-way bi-amp mode. A wide range of accessories, including transport protection, is available.

When paired with a CODA Audio subwoofer such as the G15-Sub or G18-Sub, the low frequency response is extended down to 25 Hz. This combination creates an exceptional PA system with impressive output for its compact size and weight.

The G715-Pro is designed to work exclusively with CODA Audio LINUS Loudspeaker Management Amplifiers as an integrated solution for DSP, amplification, network remote control, optimal performance and protection, as well as extensive possibilities for system tuning and monitoring.

System Solutions

NO. 1: 8x G715 PASSIVE

SYSTEM COMPONENTS:

8x G715
1x LINUS12C

NO. 2: 2x G715 PASSIVE + 2x U4

SYSTEM COMPONENTS:

2x G715
2x U4
1x LINUS12C

NO. 3: 4x G715 BI-AMP

SYSTEM COMPONENTS:

4x G715
1x LINUS12C

NO. 4: 2x G715 BI-AMP + 2x U4

SYSTEM COMPONENTS:

2x G715
2x U4
1x LINUS12C

Specification

Type: High Output 3-way Multidesign System
Application: High output short / medium throw or stage monitor
Frequency response: 50 Hz – 23 kHz (-6 dB)
Power handling AES / peak (passive): 1000 W / 4000 W
Low AES / peak: 1000 W / 4000 W
Mid / High AES / peak: 150 W / 1300 W
Sensitivity: 98 dB
Max. SPL peak*: 143 dB
Amplification, cabinets per amplifier:
LINUS5-C Optimum / Maximum: 2/2 (bi-amp) or 4/4 (passive)
LINUS10-C Optimum / Maximum: 4/4 (bi-amp) or 8/8 (passive)
LINUS12C Optimum / Maximum: 4/6 (bi-amp) or 8/12 (passive)
LINUS14 Optimum / Maximum: 4/6 (bi-amp) or 8/12 (passive)
Dispersion: 90° horizontal / 60° vertical
Components:
Low frequency: 15″ neodymium woofer, 4″ (101.6 mm) voice coil, 1000 W (AES)
High frequency: 1.4″ neodymium coaxial driver, 3.5″ (90 mm) + 1.75″ (44.4 mm) voice coil, 150 W + 80 W (AES)
Crossover: 750 Hz, 6.3 kHz passsive
Nominal impedance: 8 Ω (1+/1-)
Input connectors: 2x Neutrik™ NL4MP
Suspension: G715-Pro: M6 and M8 threaded points for use with optional U-bracket
G715: M6 threaded points for use with optional U-bracket
Enclosure material: Birch plywood
Finish: Polyurea coating
IP rating (IEC 60529): IP54
Weather protection options: Standard IP55: IP55 (direct cable)
MG1 (Marine Grade 1): IP55
Dimensions (WxHxD): 420 x 700 x 370 mm (16.54 x 27.56 x 14.57″)
Net weight: 24.5 kg / 54.01 lbs

* Measured with pink noice 6 dB crest factor. Half-space loading.

Accessories

  • COB-G515

    This post is also available in: Deutsch (German)

    Cover for 1x G515-Pro / G715-Pro

  • A15VG-PRO

    This post is also available in: Deutsch (German)

    Vertical u-bracket for G515-Pro and G715-Pro

  • A15HG

    This post is also available in: Deutsch (German)

    Horizontal u-bracket for G515-Pro / G715-Pro

  • 24481

    This post is also available in: Deutsch (German)

    Wall Mount for CoRAY / CoRAY4L Twin, fixed on CA4 / 1x CoRAY4i or CoRAY4i twin, fixed on CA4i / G515-Pro / G512-Pro / G715-Pro / G712-Pro / D12 / D20

  • GFA

    This post is also available in: Deutsch (German)

    Flying adapter for G308 / G308-Pro / G515-Pro / G512-Pro / G715-Pro / G712-Pro

  • M6 RING

    This post is also available in: Deutsch (German)

    For rigging G308 / G308-Pro / G515-Pro / G512-Pro / G715-Pro / D8 / D12 / D20

  • AK2G

    This post is also available in: Deutsch (German)

    Array kit for 2 x G515-Pro / G512-Pro / G715-Pro / G712-Pro

Downloads

FileAction
G715-Pro Data Sheet (English)Download
G715-Pro Datenblatt (Deutsch)Download
G715-Pro GLLDownload
G 715-Pro CAD Drawing L 2DDownload
G 715-Pro CAD Drawing R 2DDownload
G715-Pro CAD Drawing 3DDownload
G715-Pro Accessoires - DrawingsDownload
CODA Audio Passive and Bi-Amp switching ManualDownload
CODA Audio Weather Protection Download
