Ultra Compact 2-way Multidesign System
This post is also available in:
Deutsch (German)
CODA’s G-Series boxes are made with versatility in mind: full range systems that incorporate top end drivers; as a result, they’re suitable for a wide range of applications.
The G300 Series includes the G308-Pro and the G15-Sub, and as is always the case with CODA, it all starts with the drivers: it’s a compact, smart 2-way system with wide dispersion, incorporating top quality patented annular HF drivers with a 1.5″ voice coil, and ultra-low distortion neodymium woofers with a 2″ voice coil and double demodulation rings.
The G308-Pro boasts a power handling of 220 W, has an 8″ cone driver, and 1″ compression driver – but these are no ordinary compression drivers. The HF drivers utilise CODA’s unique CuCup technology, which dramatically reduces intermodulation distortion, and in turn, deliver the most pristine and transparent audio.
It’s also simple to mount these boxes on walls or ceilings thanks to its M6 flying points for optional U-brackets, making it a no-brainer for any touring or install application: it’s a great choice for small clubs, bands, corporate events – even as a 5.1 surround solution or a dedicated stage monitor. The sky really is the limit.
Low end reinforcement comes courtesy of the compact G15-Sub and its 15″ neodymium ultra low distortion woofer. It packs a serious punch as 1250 W, and is the perfect partner to the G308-Pro.
G308-Pro has been designed to work exclusively with CODA Audio LINUS Loudspeaker Management Amplifiers as an integrated solution for DSP, amplification, network remote control, optimal performance, protection, as well as extensive possibilities for system tuning and monitoring.
12x G308
1x LINUS12C
2x G308
2x G15-SUB
1x LINUS12C
| Type: | Ultra Compact 2-way Multidesign System |
|---|---|
| Application: | High quality short throw |
| Frequency response: | 60 Hz – 30 kHz (-6 dB) |
| Power handling AES: | 220 W |
| Program power: | 440 W |
| Peak power: | 880 W |
| Sensitivity: | 94.5 dB |
| Max. SPL Peak*: | 124 dB |
| Amplification, Cabinets per amplifier: | |
| LINUS5-C Optimum / Maximum: | 8/16 |
| LINUS10-C Optimum / Maximum: | 8/16 |
| LINUS12C Optimum / Maximum: | 8/16 |
| LINUS14 Optimum / Maximum: | 8/16 |
| Dispersion: | 90° conical |
| Components: | |
| Low frequency: | 8″ ultra low distortion cone driver, 2″ (51 mm) voice coil |
| High frequency: | 1″ compression driver, 1.5″(38 mm) voice coil |
| Crossover point: | 1900 Hz |
| Nominal impedance: | 8 Ω (1+/1-) |
| Input connectors: | 2 x Neutrik™ NL4MP |
| Enclosure material: | Birch plywood |
| Finish: | Polyurea coating |
| Suspension: | G308-Pro: M6 and M8 threaded points and flange adapter |
| IP rating (IEC 60529) | IP54 |
| Weather protection options: | Standard IP55: IP55 (direct cable) MG1 (Marine Grade 1): IP55 |
| Dimensions (WxHxD): | 230 x 471 x 260 mm (9.05 x 18.54 x 10.24″) |
| Net weight: | 9.5 kg / 20.94 lbs |
| Human EQ-switch |
* Measured with pink noice 6 dB crest factor. Half-space loading.
