CoRAY4L : Column Speaker. Line Array.

Low-mid Extension for CoRAY4

CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Size Comparison
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Photo
CoRAY4L Size Comparison

Compact low-mid frequency extension for CoRAY4, High Power handling of 700 W

  • The CoRAY4L is a compact low-mid frequency extension for the CoRAY4. The cabinet contains four 5“ ultra low distortion cone speakers and features the same CMS (Coda Mobile Suspension) as the CoRAY4 for an integrated fixing solution.


Main Features

  • Compact low-mid frequency extension for CoRAY4/CoRAY4i
  • Frequency range: 80 Hz – 1300 Hz (-6 dB)
  • High power handling of 700 W (AES)
  • Four 5″ ultra low distortion cone speakers
  • Integrated CMS (Coda Mobile Suspension) optimised for mobile use
  • Ball impact resistant – CoRAY4Li (DIN 18032-3)
  • System integration with LINUS Loudspeaker Management Amplifiers

This post is also available in: Deutsch (German)

Overview

The CoRAY4L is a compact low frequency extension for the CoRAY4. The cabinet contains four 5″ ultra low distortion cone speakers and features the same CMS (CODA Mobile Suspension) as the CoRAY4 for an integrated fixing solution.

CoRAY4L can be combined with one or two CoRAY4, and optionally with another CoRAY4L in a vertical array creating a line source length of up to three meters.

This improves low-mid reproduction and increases long throw capability. A system that convinces with high fidelity, scalability and excellent speech intelligibility.

Models

  • CoRAY4L Optimised for touring applications
  • CoRAY4Li Optimised for permanent (fixed) installations

Specification

Type: Low-mid extension for CoRAY4/CoRAY4i
Frequency response: 80 Hz – 1300 Hz (-6 dB)
Power handling AES: 700 W
Peak power: 2800 W
Sensitivity: 97 dB
Max. SPL peak: 131 dB
Amplification, Cabinets per Amplifier:
LINUS5-C Optimum / Maximum: 4/8
LINUS10-C Optimum / Maximum: 4/8
LINUS14D Optimum / Maximum: 4/8
LINUS10 Optimum / Maximum: 2/4
Components: 4x 5″ woofer, 1.5″ (38 mm) voice coil, 170 W (AES)
Nominal impedance: 4 Ohm (1+/1-)
Input connectors: 2x Neutrik™ NL4MP
Suspension: CoRAY4L: CMS (CODA Mobile Suspension) + flange adapter
CoRAY4Li: M6 threaded points for use of optional U-bracket
Enclosure material: Birch plywood
Finish: Black polyurea coating
IP rating (IEC 60529) IP54
Weather protection options: Standard IP55: IP55 (direct cable)
MG1 (Marine Grade 1): IP55
Dimensions (WxHxD): 152 x 758 x 214 mm / 5.98 x 29.84 x 8.42″
Net weight: 13.2 kg / 29.1 lbs

Accessories

  • CF4

    This post is also available in: Deutsch (German)

    Flying frame for CoRAY4 / CoRAY4L
    to be fixed on CMS (Coda Mobile Suspension)

  • CA4

    This post is also available in: Deutsch (German)

    Twin adaptor for 2x CoRAY4 / CoRAY4 + CoRAY4L
    to be fixed on CMS (Coda Mobile Suspension)

  • TV4C

    This post is also available in: Deutsch (German)

    Clamp for TV spigot

  • TV4

    This post is also available in: Deutsch (German)

    TV spigot for CF4 flying frame

  • CoRAY4 Twin

    This post is also available in: Deutsch (German)

    using CA4, CF4, TV4 and TV4C

  • CF4I

    This post is also available in: Deutsch (German)

    Flying frame for CoRAY4i and CoRAY4Li. Max load 60kg

  • CoRAY4i Twin

    This post is also available in: Deutsch (German)

    using CA4i and CF4i

  • CA4I

    This post is also available in: Deutsch (German)

    Twin adaptor for 2x CoRAY4i

  • C4VC

    This post is also available in: Deutsch (German)

    U-bracket for CoRAY4 / CoRAY4L and CoRAY4i

  • C4WM

    This post is also available in: Deutsch (German)

    Wall mount bracket for CoRAY4 / CoRAY4L and CoRAY4i

  • 24481

    This post is also available in: Deutsch (German)

    Wall Mount for CoRAY / CoRAY4L Twin, fixed on CA4 / 1x CoRAY4i or CoRAY4i twin, fixed on CA4i / G515-Pro / G512-Pro / G715-Pro / G712-Pro / D12 / D20

  • COB-CoRAY4

    This post is also available in: Deutsch (German)

    Transport bag for 1x CoRAY4 / CoRAY4L

Downloads

FileAction
CoRAY4L DatasheetDownload
CoRAY4L CAD Drawing 2DDownload
CoRAY4L CAD Drawing 3DDownload
CoRAY4Li CAD Drawing 2DDownload
CoRAY4Li CAD Drawing 3DDownload
CoRAY4L Accessories - DrawingsDownload
CoRAY4Li Accessories - DrawingsDownload
CODA Audio Weather Protection Download
