SCN-F : Sensor Controlled Subwoofer.

15" Bass Extension with SC Technology for N-RAY

SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Size Comparison
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Photo
SCN-F Size Comparison

SCN-F is a 15" sensor controlled low frequency extension system operating from 35-200 Hz

  • Overlapping both the low range of N-RAY and the SCV/SCP subwoofers – providing more energy and control in the lower range of the system.


Main Features

  • 15” sensor controlled bass extension
  • Extended low frequency range: 35 Hz – 200 Hz (-6 dB)
  • High power handling: 1500 W (AES)
  • Sensor Control Technology
  • Dynamic Airflow Cooling (DAC) ensures exceptionally high sound pressure and low power compression
  • The feedback loop control ensures extreme fast transient response and ultra low distortion
  • Subwoofer arrays can be curved for perfect time alignment with N-RAY
  • Increases the long throw capability of N-RAY
  • Enhances the systems low frequency headroom
  • Flyable or ground stackable configurations
  • Rigging is compatible with N-RAY
  • System integration with LINUS Loudspeaker Management Amplifiers

This post is also available in: Deutsch (German)

Overview

SCN-F Uncovered

Targeted towards theatres, houses of worship, corporate events, sport venues, and live sound venues, the SCN-F is a 15″ sensor controlled low frequency extension system operating from 35-200 Hz, overlapping both the low range of N-RAY and the SCV/SCP subwoofers – providing more energy and control in the lower range of the system.

Weighing just 33 kg, and boasting a power handling of 1500 W (AES), the SCN-F extends the LF throw capability of the N-RAY system significantly. The flying system allows for vertical curving of the SCN-F too, ensuring perfect time alignment with N-RAY when flown behind or to the side.

Dynamic Airflow Cooling (DAC).

Putting that immense amount of power into a compact enclosure required a new enclosure design and a new thermal concept. The SCN-F front baffle and vents are made from aluminum with all drivers mounted into it. The aluminum vents are optimised to maximise airflow increasing the thermal capacity of the system. Applying more power increases the airflow in the vents conducting more heat away from the drivers and distributing that heat outside the enclosure. The patented DAC technology dramatically improves heat dissipation increasing twice the power handling and the maximum sound pressure of the system.

State of the Art Neodymium Cone Driver.

SCN-F is equipped with an extremely long excursion neodymium ultra low distortion driver. Three aluminium shorting rings reduce intermodulation distortion, minimising induction variation whilst reducing thermal compression, dramatically reducing the distortion of a typical low frequency driver at larger excursions.

The 15″ driver contains an integrated velocity sensor that measures the diaphragm movement in real time. The LINUS14 compares this with the audio input signal and adjusts its driving current to correct any driver inaccuracies – the key advantage being a very extended and controlled response.

SCN-F is designed to work exclusively with dedicated CODA Audio amplifiers and racks as an integrated solution for DSP and sensor control, amplification, network remote control, and diagnostics, ensuring optimal performance and protection.

System Solutions

System 1: 24x N-RAY + 8x SCN-F + 8x  SCV-F + 4x  M-RACK

SYSTEM COMPONENTS:

24x  N-RAY
8x  SCN-F
8x  SCV-F
4x  M-RACK

System 2: 12x N-RAY + 4x SCN-F + 4x SCV-F + 2x M-RACK

SYSTEM COMPONENTS:

12x  N-RAY
4x  SCN-F
4x  SCV-F
2x  M-RACK

Rigging Examples

N-RAY Rigging Example 2

  • 2x SCN-F
  • 6x N-RAY

N-RAY Rigging Example 3

  • 4x SCN-F
  • 12x N-RAY

N-RAY Rigging Example 4

  • 4x SCN-F
  • 12x N-RAY

N-RAY Rigging Example 5

  • 3x N-RAY
  • 1x SCN-F
  • 6x N-RAY

N-RAY Rigging Groundstack Example 6

  • 3x SCN-F
  • 3x N-RAY

Specification



Type: 15″  Bass extension with SC Technology for N-RAY
Frequency response: 35 – 200 Hz (-6 dB)
Power handling AES / peak (passive): 1500 W / 6000 W
Max. peak SPL (with LINUS14):* 139 dB
Amplification, Cabinets per Amplifier
LINUS5-C Optimum / Maximum: N/A
LINUS12C Optimum / Maximum: N/A
LINUS14 Optimum / Maximum: 8/12
LINUS10 Optimum / Maximum: 4/6
Dispersion Horizontal: N/A
Dispersion Vertical: N/A
Components Low frequency: 15″ neodymium ultra-low distortion woofer, 4″ (101.6 mm) VC
Components Mid/High frequency: N/A
Crossover point: N/A
Input Connectors: 2x Neutrik™ NL4MP + 1x NC3MAV
Nominal impedance LF / MF+HF: 8 Ω (1+/1-)
Enclosure material: Hybrid – Birch plywood and Aluminium
Suspension Integrated, allows curving of 0°, 2° or 5°
IP rating (IEC 60529): IP54
Weather protection options: Standard IP55: IP55 (Amphenol connectors)
MG1 (Marine Grade 1): IP55
Dimensions (WxHxD): 518 x 418 x 595 mm / 20.39 x 16.46 x 23.43″
Net weight: 33 kg / 72.75 lbs

* Pink noise 6 dB crest factor.Half-space loading.

Accessories

  • FR-NR

    This post is also available in: Deutsch (German)

    Frame for flying or ground stacking N-RAY and SCN-F, incl. EXBAR-NR, NADS, shackles

  • NR-LINK

    This post is also available in: Deutsch (German)

    Rear connection adapter for flying 9 x N-RAY below SCN-F

  • NGA

    This post is also available in: Deutsch (German)

    Ground stacking adapter for N-RAY

  • DOT-SCN-F

    This post is also available in: Deutsch (German)

    Transport dolly for up to 3 x SCN-F

  • CO-N-SUB

    This post is also available in: Deutsch (German)

    Protection cover for 1x N-SUB/ SCN-F

  • CO-N-SUB EX

    This post is also available in: Deutsch (German)

    Protection cover extension for 1 x N-SUB / SCN-F, compatible with CO-N-SUB

  • CAH-SCP-10

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor system cable, 10 m
    1xNL4 speakon® +1x 5-POLXLR-M
    2xNL4 speakon® +2x 3-POLXLR-F

  • CAH-SCP-20

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor system cable, 20 m
    1xnl4 speakon® +1x 5-polxlr-m
    2xnl4 speakon® +2x 3-polxlr-f

  • CAH-SCP-Y

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor cable splitter

  • CAH-SCP-EX-10

    This post is also available in: Deutsch (German)

    Hybrid speaker and sensor cable extension 10 m

  • CAL4SP-1.5

    This post is also available in: Deutsch (German)

    4-pole loudspeaker cable, 4×4 mm, 1.5 m
    1x nla4 speakon®

Downloads

FileAction
SCN-F Data Sheet (English)Download
Loading Capacity Calculation (N-RAY_SCN-F)Download
SCN-F CAD Drawing 2DDownload
SCN-F CAD Drawing 3DDownload
SCN-F Accessories - DrawingsDownload
CODA Audio Rigging Systems maintenance N-RAY and SCN-FDownload
CODA Audio Cardioid DeploymentsDownload



CODA Audio Weather Protection Download
