OVERVIEW
The LINUS6.4 is a four-channel DSP networkable installation amplifier delivering 4 x 1500 W of clean power in a convenient and lightweight 19”/1U package.
Advanced Class D discrete power stages with DC-coupled DACs, together with a high-efficiency SMPS with PFC to provide unrivalled power density and minimal thermal dissipation.
The innovative PCB layout design integrates DSP, four amplifiers, and SMPS on a single PCB for enhanced sound quality, pinpoint control, and rugged protection.
The four audio inputs are selectable, you can choose between analog, LiNET, Dante digital audio network and simply and easily route to any of the four outputs via the input matrix.
The advanced DSP processor enables the integration of sophisticated audio algorithms including phase linear DS-FIR filters, these provide perfect linearity and superior sound performance, plus advanced look-ahead and frequency-dependent limiters. The end result is increased system headroom and sonic fidelity, even under heavy use conditions.
Specification
| GENERAL |
| Number of output channels |
4 |
| Output stage |
Class D |
| Internal samplerate / bit-depth |
48 kHz / 32 bit |
Signal-to-noise ratio
(22 Hz – 20 kHz, 4 Ω – analogue input) |
>108 dB (unweighted) SE
>107 dB (A-weighted) SE |
Signal-to-noice ratio
(22 Hz – 20 kHz, 4 Ω – digital input) |
>107 dB (unweighted) SE
>110 dB (A-weighted) SE |
Frequency response
(8 Ω load with CLEAR preset) |
20 Hz – 20 kHz = (+0.0 dB /-1.0 dB) |
THD+N & IMD
(4 Ω load @ 1/2 output power) |
20 Hz – 20 kHz = < 0.005% |
Latency
(input to loudspeaker output) |
TBC |
| Protection circuits |
Inrush current limiter
Thermal limiter
Output DC
SMPS over-current
Output overload |
| LED indicators |
Mute status
Limit
Signal
Protection
Ethernet connected / IP address
Power on / Limiting |
| Ethernet connection |
1 x 100 Mbps RJ45 Control
2 x 1Gbps RJ45 Dante |
| AC Mains |
| AC mains input connector |
EURONET C14 |
| AC mains voltage |
90 V = Minimum
265 V = Maximum |
| AC mains frequency |
47 – 63 Hz |
Power consumption*
(1/4 power = 500 W @ 4 Ω to represent typical music signal) |
Amplifier in standby <= 15 W
Amplifier idle <= 25 W
Amplifier ¼ power = 1700 W |
| Input |
| Input sources |
Analog, LiNET & Dante |
Analogue input impedance
(balanced) |
44 kΩ |
| Maximum input level (analogue differential) |
+21 dBu / 8.7 Vrms |
| Input connections |
4x PHOENIX 3P Analog IN
1X RJ45 LINET IN (8x CH)
1x RJ45 LINET LINK (8x CH)
2x RJ45 Dante (optional) |
Supported digital input formats
(internal SRC) |
32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz / 176.4 kHz / 192 kHz |
| Output |
RMS output power*
(20 Hz – 20 kHz, THD <1%)
(all channels driven) |
4x 1500 W @ 2 Ω SE
4x 800 W @ 4 Ω SE
4x 500 W @ 8 Ω SE
2x 3000 W @ 4 Ω BTL
2x 1600 W @ 8 Ω BTL
1x 3000 W @ 4 Ω BTL + 2x 1500 W @ 2 Ω SE |
Peak output power*
(20 Hz – 20 kHz, 6 dB Crest Factor)
(all channels driven) |
1000 W pk @ 8 Ω SE
1500 W pk @ 4 Ω SE
3000 W pk @ 2 Ω SE
3200 W pk @ 8 Ω BTL
6000 W pk @ 4 Ω BTL |
| Maximum output voltage* |
+/- 90 V pk SE
+/- 180 V pk BTL |
| Maximum output current* |
+/- 50 A pk |
Damping Factor
(8 Ω load, 1 kHz & below) |
2500 |
| Minimum output load |
2 Ω nom SE
4 Ω nom BTL |
| Power output connections |
2x PHOENIX 4P (Connector supplied with amplifier) |
| Thermal |
| Operating temperature |
+5°C to +55°C
41°F to 131°F |
Thermal output
(BTU/h) |
85.3 = Idle
700 = 20 %
1621 = 50 %
3156 = 100 % |
Thermal output
(kWh) |
0.025 = Idle
0.205 = 20 %
0.475 = 50 %
0.925 = 100 % |
| Cooling |
2x thermally controlled fans
Hot air expelled at rear |
| Physical |
| Dimensions (WxHxD) |
483 x 44 x 345 mm / 19” x 1.73” x 13.58” (1U)
(size including back mounting ears) |
| Net Weight |
5.75 kg / 12.68 lbs. |
* Typical values – some variation may exist due to component tolerances.
SE = Single Ended
BTL = Bridge Tied Load
**Voltage range should not be exceeded. Amplifier output power performance will degrade below nominal voltage & increase above nominal voltage.
